Services

Experts in mechanical design | Experts in manufacturing.
Experts in product design | Experts in 3D printing.

Mechanical Design

Specialist equipment | Test Rigs | Tooling
Over 20 years mechanical design experience.

Contract CAD

20+ years SolidWorks experience.
20+ years AutoCAD experience.

Cost Reduction

Increase your profits by reducing your manufacturing costs.

Medical Device Design

Orthopaedic Implants & Instruments
Instrument trays and layouts

3D Printing

3D SLA & FDM printing | Material Choices
Prototypes | Fixtures | Tooling

Product Design

Innovative consumer products, from rough sketch to production ready and beyond.

Fees & Guarantees

Our clients deserve value for money!
White Horse CAD will never invoice for more time than we spend on your project*. We track time spent on each project to the minute and each section of time logged will be itemised so you can see exactly what we have been doing. (*Minimum project length 2 hours).

We take pride in our work!
If we miss a dimension or make a spelling mistake on your engineering drawings we will make ALL corrections free of charge. (Client errors or omissions excluded)

Our 3D prints are accurate!
If a 3D print we supply has a dimensional error greater than 0.5mm you will get your print for free!

You may qualify for a FREE 3D Print
If your project spend is over £2500 in any month your first 3D print in that month will be FREE OF CHARGE.

Contract CAD

From:
£40+VAT
per hour

  • Mechanical Design
  • Product Design
  • Engineering Drawings
  • Legacy Transfer
  • Reverse Engineering
Ask for more Information
3D Printing

From:
£20+VAT

  • FDM
    ABS, HiPs, ULTRAT & more
    Max. Print Size:
    200mm X 20mm X 180mm
  • SLA
    Basic White, Pro Black, Flexible
    Max. Print Size:
    74mm X 132mm X 175mm
find out more

Introductions....

Born from a passion to deliver high quality engineering design services.
Tim Bird MIED

Tim Bird MIED

Managing Director

Tim has been an engineer since the mid 1980's. Starting his trade a sheet metal worker and then becoming a toolmaker in the early 1990's. Tim's design career started in Frome during the mid 90's. He went on to hold 2 senior design engineer roles working for multinational companies in the medical device industry.

What our clients say

This is what some of our clients have said about White Horse CAD's design and project management services
Duncan Hunt

Duncan Hunt

Hunt Developments Ltd

Tim is highly professional and very easy to work with. His combination of skills and experience have proved invaluable on several projects and we would not hesitate to use his services in the future.

Dr Alex Dickinson

Dr Alex Dickinson

University of Southampton

I have been lucky to work with Tim on various projects since 2006. He is simply a design genius. Tim is a great communicator of design, and works to perfection, but perhaps his greatest strength is in his design insight, in complex systems and mechanisms.

John Lamborn

John Lamborn

AT Ortho Limited

Following several years first-hand experience, we would be delighted to endorse Tim for project management, mechanical engineering, engineering design, engineering drawing, solidworks, 3d design, computer-aided design (cad), jig and fixture design and product design works

Dr Anne Roques

Dr Anne Roques

Pulsar R&D

I have worked with Tim on innovative development projects (orthopaedics implant and instruments), for which Tim was the senior design engineer. Tim is a gifted engineer, who has designed multiple implants/instruments systems and associated fixtures for verification. WHC can supply rapid prototypes, which are a great aid. In my experience, Tim‘s work is always of high quality.

Simon Wallis

Simon Wallis

ELIQUO | HYDROK Ltd

‘We have used White Horse CAD to produce manufacturing drawings and material requisition for us.
Tim’s work is clear, concise and well presented. He works quickly to turn around the work we require which helps to maintain our manufacturing schedules. I would recommend White Horse CAD to any potential customer looking to have the same work carried out.’

Lyndon Beer

Lyndon Beer

LGB Electrical

I asked Tim if he could find a better solution to a tool I use to fit dimmer switches. The manufacturer of the switches supply a plastic tool with each unit but the tool breaks easily. Tim took the original tool and converted it to a 3D CAD, he then lined up a local engineering company to make it. Needless to say, that from start to finish Tim has been professional and very informative. I would not hesitate to recommend him to anyone needing CAD Design.

Richard Thomas

Richard Thomas

KLAW Products Ltd

Excellent support and a very capable engineer! Looking forward to working together again in the future.

Toby Hunt

Toby Hunt

Hunt Development Ltd

If you are after innovative ways to solve project challenges I would recommend teaming up White Horse CAD as a Research and Development Partner.

Daniel Swift

Daniel Swift

WS Swift Ltd

We have worked with Tim from White Horse CAD on multiple projects over the past year. They have become a trusted part of our team. Tim always delivers projects on time and to a very high standard. I have no problem in recommending White Horse CAD to other businesses looking for CAD support.

WHC News

| Never miss another article |
| Sign up to our newsletter by clicking the button above |

Can we save you money?

How can an independent design consultant save you money? Do you design or make a product? Do you need more design capacity than your team can support? Would you like to employ a design engineer Read more…

Wobbler Engine Drive Shaft

This is the 14th in our series of posts where we are sharing drawings for the White Horse CAD Wobbler Engine. This week we will look at the Wobbler Engine Drive Shaft. Next week we Read more…

Business Against Poverty

White Horse CAD have recently started to support an amazing charity Business Against Poverty. Who They Are Business Against Poverty were founded in 2009, it currently has more than 100 businesses attached to it and Read more…
